OPERATING LIMITS
1.Suction lift up to 8m
2.Clean water, non-corrosion liquid
3.Fluid temperature up to 40 °C
4.Maximum ambient temperature 40 °C
STRUCTURAL CHARACTERISTICS
1. Brass impeller
2.100% Copper winding
3. Single/Three-phase, 50/60Hz (as customized)
4.Stainless steel mechanical seal (graphite to ceramic)
5. Protection IP44
6. C&U bearing or local bearing
7.Thermal overload protector
8. Anti-rust shaft (Hi-Cr plated or welded stainless steel)
PERFORMANCE DATA AT n=2900 rpm/min
Performance parameter
Model | Inlet/Outlet | Power | Q(m³/h) | 0 | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 2.1 | 2.4 | 2.7 | 3.0 | 3.6 | 4.2 | 4.8 | 6.0 | 7.2 | 8.1 | 9.6 | ||
Single phase | Inch | kW | HP | (L/min) | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 700 | 80 | 100 | 120 | 140 | 160 |
JSW3CL | 1"x1" | 1.1 | 1.5 | H(m) | 42 | - | 40 | 39 | 38 | 37 | 36 | 35 | 34 | 33 | 32 | 30 | 28 | 26 | 23 | 20 | 17 | 15 |
JSW3BL | 1"x1" | 1.5 | 2.0 | 51 |
| 48 | 46 | 45 | 44 | 43 | 42 | 41 | 40 | 39 | 37 | 35 | 33 | 30 | 27 | 24 | 22 | |
