OPERATING LIMITS
1.PH level from 6.5-8.5
2.Maximum sand content is 0.1%. Passage of suspended
3.Solids up to 0. 2mm
4.Voltage fluctuation range:0.9-1.1 times of the rated value
5.Immersion depth from 0. 5m-5m
6.Max medium temperature+40°C
7.Max ambient temperature+40°C
MOTOR INFORMATION
1.Two-pole induction motor
2.Single phase/three phase, 50/60hz (on demand)
3.Thermal protector for single phase
4.Insulation class: B
5.Protection class:IPX8
MATERIAL
1.Pump body: Cast iron
2.Motor housing: Aluminum/iron
3.Impeller: Aluminum
4.Motor wire: Copper
5.Mechanical seal: Ceramic&Graphite
6.Shaft: 45#steel/stainless steel
PERFORMANCE PARAMETER
Model | Inlet/Outlet | Power | Max.Diving depth | Max.Flow | Max. Head | |
Single phase | Inch | KW | HP | m | m3/h | m |
QDXC-1.5-17-0.37 | 1" | 0.37 | 0.5 | 5 | 6.0 | 18 |
QDXC-1.5-25-0.55 | 1" | 0.55 | 0.75 | 5 | 5 | 25 |
QDXC-3-18-0.55 | 1.25" | 0.55 | 0.75 | 5 | 8 | 20 |
QDXC-10-12-0.55 | 1.5" | 0.55 | 0.75 | 5 | 15 | 18 |
QDXC-15-7-0.55 | 2" | 0.55 | 0.75 | 5 | 22 | 8 |
QDXC-1.5-32-0.75 | 1" | 0.75 | 1 | 5 | 6 | 33 |
QDXC-3-24-0.75 | 1" | 0.75 | 1 | 5 | 9 | 25 |
QDXC-8-18-0.75 | 1" | 0.75 | 1 | 5 | 15 | 20 |
QDXC-10-16-0.75 | 1" | 0.75 | 1 | 5 | 15 | 20 |
QDXC-25-6-0.75 | 1" | 0.75 | 1 | 5 | 32 | 9.5 |
QDXC-3-30-1.1 | 1" | 1.1 | 1.5 | 5 | 10 | 30 |
QDXC-15-14-1.1 | 2.5" | 1.1 | 1.5 | 5 | 28 | 17 |
| QDXC-40-6-1.1 | 3" | 1.1 | 1.5 | 5 | 52 | 10 |
| QDXC-40-9-1.5 | 3" | 1.5 | 2 | 5 | 60.5 | 11.2 |
| QDXC-25-12-1.5 | 2.5" | 1.5 | 2 | 5 | 42 | 15 |
| QDXC-50-9-2.2 | 4" | 2.2 | 3 | 5 | 52.5 | 11.5 |
QDXC-75-8-3 | 4" | 3 | 4 | 5 | 100 | 15 |
