PERFORMANCE DATA

PERFORMANCE CURVE AT N=4000 RPM

APPLICATION SITUATIONS OF FREQUENCY BOOSTER PUMP

OPERATING CONDITIONS

1. Power input: 24V / 36V DC adapter, the maximum pressure of the booster system should be no more than 5bar for the pump motor input current;

2. Ambient temperature: 0~40°C;

3. Liquid temperature; 0~90°C;

4. Medium: the medium should be liquid and it should be clean, thin, non-corrosive, non-flammable, explosive, and free of solid particles, and whose properties are similar to Glean water.

ADVANTAGES

1. Intelligent frequency conversion and energy saving: pump takes high-speed permanent magnet frequency conversion Brushless motor.  It can save energy more than 60% than normal booster pump. It operates stably and effectively.

2. Work silent. Pump is taken internal water-cooled sliding bearing structure. The noise made by it is less than 40 dB.

3. Multi-speed available (flow switch) : There are multiple gears for users to choose. Users can choose which gear according to own needs.

4. Wide voltage use: 160-240V wide voltage use without obstacles to ensure stable performance.

5. Safe. The pump is powered by Low-voltage which is less than 36V. Safe and reliable.
